Immersion cylinder, brass, 1000 ml, hxØ 450x75 mm

Immersion cylinder, brass, 1000 ml, hxØ 450x75 mm, Part number 5365-7000-BK, Buy now form Bürkle at Dawnscientific

The dipping bottles for the Ex protection area are made of nickel-plated brass, therefore they do not oxidize.

Dipping vessels can be used for point sampling, all-layer samples and bottom sampling.

Immersion cylinder for sampling crude oil, liquid mineral oil products, fuels, special and test fuels, fuel oils, petroleum and liquid lubricants in Explosion Categories IIA, IIB and IIC. Completely made from non-spark producing materials, nickel-plated.

Features

• Screw-off top enables easy cleaning
• High weight for fast lowering
• Robust handle
• Tested for use in the Ex protection zone 0

Applications

Dipping containers are used in various areas to collect liquids for sampling. Bürkle produces the most comprehensive collection of dipping containers by a long way, the right product for every use as it were.

Bürkle offers dipping bottles and immersion cylinders for sediments, for the area of environmental issues, for chemically aggressive products, for petrochemistry, for the ex protection area etc.

Point sampling

• Two lowering cables are required for this (bearer cable and hauling cable).
• Lower the immersion cylinder to the required depth.
• When the target has been reached, pull on the hauling cable, the valve opens.
• The sample flows into the bottle.
• Release the hauling cable. The valve closes. Pull the cylinder back on the bearer cable.
• Empty the cylinder via the valve at the bottom.

Bottom sampling

• Lower the immersion cylinder on the cable to the ground.
• The valve opens automatically because of the immersion cylinder's own weight.
• The sample flows into the cylinder.
• Pull the cylinder back on the cable, the valve closes independently.
• Empty the cylinder via the valve at the bottom.
